JUKI DDL-8700-7 UBT LOCKSTICH HEAD ONLY MEDIUM WEIGHT
Description / JUKI DDL-8700-7 UBT LOCKSTICH HEAD ONLY MEDIUM WEIGHT
Juki DDL-8700-7
- 1-needle, Medium-Weight Lockstitch Machine with Automatic Thread Trimmer
Standard model of JUKI 1-needle lockstitch machines. The DDL-8700 is provided with the "new model control box" and the "new model compact servomotor," thereby substantially saving energy.
Machine head design that was developed in pursuit of beauty
The optimum-balance and highly rigid machine head were created using the latest 3D-CAD design technology. Thanks to its low vibration and low noise feature, the machine head provides the operator with a comfortable work environment. In addition, the distance from the machine arm to the needle on the front of the machine head is sufficiently wide to allow easy handling of the sewing material.
The machine inherits the desirable features, such as high-speed stitching performance 5,000sti/min, extreme stitching performance, ease of operation, and reliability, from the highly evaluated previous JUKI lockstitch machines. (DDL-8700: 5,000 sti/min.)
The machine provided as standard with attachment mounting seats
The machine is provided as standard with extra attachment mounting seats for attachment of new auxiliary parts in the future. The extremely high durability of the seats ensures an extended service with frequent replacement of attachments.
![](/media/wysiwyg/machines/Juki/JukiDDL8700/001.jpg)
Sewing mechanism that demonstrates outstanding responsiveness to materials to be sewn
By thoroughly investigating and modifying the sewing mechanisms in order to achieve low-tension sewing, the machine flexibly responds to various kinds of materials and produces beautiful seams of consistent quality.
The machine has easy-to-operate functions to achieve improved operability
By providing a presser foot with a higher lift (13mm), a light-touch stitch dial, a throat plate with marker grooves that can be used as guide for seam allowance, and other easy-to-operate functions, the burden on the operator is lightened, and productivity is further increased.
![](/media/wysiwyg/machines/Juki/JukiDDL8700/002.jpg)
The new model control box, which energy-saving mode is provided
The new model control box SC-920C has been newly developed. The control box is resistant to voltage fluctuations, noise and vibration.
The new model control box is provided with an energy-saving mode for the first time in a control box for sewing machines. It reduces power consumption during standby time when the motor is not rotating by approximately 25% (in comparison with the SC-910N).
In addition, the current DDL-8700 is lavished with the latest energy-saving technologies, including the adoption of the latest compact servomotor M92, to be more friendly to the environment, as well as to provide the power reducing effect and to increase productivity.
![](/media/wysiwyg/machines/Juki/JukiDDL8700/003.jpg)
Technical Specifications
Model | Juki DDL-8700-7 |
---|---|
Application | Medium-weight |
Max. sewing speed | 5,000sti/min* |
Max. stitch length | 4mm |
Needle bar stroke | 30.7mm |
Lift of the presser foot | By hand: 5.5mm, By knee: 13mm |
Needle (at the time of delivery) | DB×1 (#14) #9~#18 134 (Nm90) |
Feed dog | 4-row |
Hook | Automatic-lubricating full-rotary hook |
Lubrication | Automatic |
Lubricating oil | JUKI MACHINE OIL 7 (equivalent to ISO VG7) |
Automatic reverse feed function | Provided as standard |
Control box | SC-920C |
Machine motor | Compact-size servomotor M92 (450W) |
Power requirement | Single-phase 100~240V, 3-phase 200~240V |
Power consumption | 320VA |
Weight | Machine head: 30kg / 35kg (with AK), SC-920C: 3kg, M92: 3.5kg |
More Information
Part No | JUKIDDL87007 |
---|---|
Weight (KG) | 36.000000 |
Manufacturer | Juki |
