Description / JUKI DLM-5200ND 3.2MM 1 NEEDLE LOCKSTITCH VERTICAL EDGE TRIMMER
Juki DLM-5200N
- 1-needle, Lockstitch Machine with Edge Trimmer.
The highly efficient lockstitch machine which assures the consistent quality of finished seams comes with a sharp knife capable of cutting various types of material.
Beautifully finished lockstitched seams
The thread take-up, feed mechanism, and thread path have been improved so as to respond to material changes.
A consistent, beautiful seam finish is therefore attained.
The knife is so sharp that it can cut any type of material
The knife is designed so that the angle can be changed as desired, allowing the knife to be easily applied to any type of material.
During operation, the type of stitching can be easily changed between lockstitch alone and lockstitch with knife
The knife can be attache by simply pressing the presser plate on the machine arm. The knife is removed also by the simple operation of the knob. Thus the type of stitching, such as with or without knife, can be changed with ease.
The maximum stitch length for the DLM-5200N has been increased to 5mm
The stitch length can be adjusted using the dial.
The exclusive arm-shaped machine head makes the material easier to handle
The arm shape of the machine head has been adopted to enhance ease of operation.
The operating noise and vibration of this model are far less than its predecessors
The operating environment has been greatly improved to allow the operator to work comfortably with this machine.
This model is designed as the optimum for high-speed sewing
This model is made of special alloy steel, and a feed mechanism and system have been incorporated to make the machine the optimum for high-speed operation. As a result, this model demonstrates a consistent sewing performance during high-speed operation.
Technical Specifications
| Model | Juki DLM-5200N |
|---|---|
| Sub-Gauge (Distance between the needle and the knife) | Juki DLM-5200N - 3.2mm (1/8") Standard |
| Max. sewing speed | 4,500sti/min* |
| Max. stitch length | 5mm (normal/reverse feed) |
| Needle bar stroke | 30.7mm |
| Lift of the presser foot | By hand: 4mm, By knee: 10mm |
| Needle (at the time of delivery) | DB×1 (#14), For JE: 134 (Nm90) |
| Hook | Automatic-lubricating full-rotary hook |
| Max. thickness of the material to be cut | 4mm |
| Lubrication | Automatic |
| Lubricating oil | JUKI New Defrix Oil No.1 (equivalent to ISO VG7) |
| Weight of the machine head | 30kg |
*“sti/min”stands for“ Stitches per Minute”
