JUKI MH-484U DIFFERENTIAL FEED SINGLE NEEDLE CHAINSTITCH

Juki MH-484U 1-needle, Double Chainstitch Differential-feed Machine
Pricing and Availability on Request
Contact Us for Quote

Why Buy from Us?

  • You are dealing with the official Juki Sewing Machine UK Importing and Distributing Network
  • Your machine enquiry will be passed onto your local Juki dealer who will quote, setup, and install your new machines. As well as providing full after sales support and warranty
  • Our centralised distribution warehouse supplies Juki machinery to all Juki Traders, providing the best possible service and local contact for your sewing requirements

Description / JUKI MH-484U DIFFERENTIAL FEED SINGLE NEEDLE CHAINSTITCH

Juki MH-484U

1-needle, Double Chainstitch Differential-feed Machine

The machine finishes beautiful seams in elastic and light-weight materials. Furthermore, the differential-feed can be adjusted with the simple operation of a lever, thereby enabling the machine to respond to the requirements of many different kinds of sewing.

Change of sewing method with a simple lever operation

The sewing method can be alternated between stretch stitching and shirr stitching with the simple operation of a lever. This lever is also used to adjust the differential-feed ratio.

The machine is capable of gathering and partial shirring

A gathering attachment (S060), intermittent gathering attachment (S061) and partial shirring device (PF5) are optionally available to enable the machine to perform consistent gathering and partial shirring.

Replaceable gauges such as the gauge for light-weight materials and the urethane feed dog are prepared in accordance with the applications of the machine.

The machine is provided with mechanisms to enable upgraded sewing

The machine comes with a thread spreading mechanism and an adjustable needle guard to prevent stitch skipping. The thread clamp mechanism, tension release mechanism and needle thread draw-out mechanism enable the machine to leave thread of a uniform length after thread trimming, and prevent slip-off of the needle thread. All of these mechanisms contribute to upgraded sewing.

Safety stitching or reverse feed stitching with a simple lever operation

Safety stitching (condensation stitching) the perfect method of preventing loose stitches, or reverse feed stitching (back-tacking) can be alternated through the simple adjustment of the stopper of the reverse feed lever. Either sewing method can be used.

Beautifully finished seams

Provided with a sliding presser foot and a silicone oil lubricating unit as standard, stitch skipping and puckering are prevented. Furthermore, the silicone oil lubricating unit prevents the needle from overheating, and allows foundation yarn or synthetic thread to be used without breakage during sewing. These features assure beautifully finished seams with consistency for light- to medium-weight materials.

APPLICATION FOR MH-484 SERIES

Application Details
Men's Shirts Attaching yokes on the back
Slacks, pantaloons, ski pants Attaching Wait Belts, joining sides, seam insides, or hip seams
Coats, blazers Sewing the center of the back, joining sides, sewing sleeves, belts, collars, and sewing the facing on to the front.
Skirts Sewing the center and joining sides
One-piece suits, blouses, negligees Making pleats or gathers
Uniforns, jumpers Sew side and sew interlining on the wrong side of the materials
interior Decorations Making pleats or gathers

Technical Specification

Model name Juki MH-484U
Feed system Differential-feed
Max. sewing speed 5,500rpm
Stitch length Main feed: 1~4mm
Differential-feed: 1~5.6mm
Top-feed amount -
Differential-feed ratio Max. gathering stitching 1: 3
(standard 1: 1.5)
Max. stretch stitching 1: 0.5
Lift of the presser foot By hand: 5mm, By knee: 10mm
Needle bar stroke 30mm
Needle TV × 7 (#11) #9~#18
Stitch length adjustment By dial
Safety stitch Condensation stitch/reverse stitching (by feed lever)
Looper system Inclined crank
Looper stroke 21.5mm
Looper stroke of the front and rear 2.1~3.3mm
Speed control -
Lubrication Automatic
Lubricating oil JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
Motor output -
Power requirement -
Power consumption -

*"sti/min" stands for "Stitches per Minute."
*(1) From 500rpm to the Max. sewing speed determined by the pulley used (externally adjustable)

Product Attachments

document-text
Juki MH-484 Series Brochure (412.18 kB)
document-text
Juki MH-484 Series Parts Book (2.83 MB)

More Information

Part No JUKIMH484U
Weight (KG) 0.100000
Manufacturer Juki
