JUKI MO-6716DA-DE6-307 3.2 x 4MM 5 THREAD OVERLOCK DRY HEAD
Juki MO-6716DA-DE6-307
- Semi-dry-head, 2-Needle 5-Thread, High-speed, Light- to Medium-Weight Overlock / Safety Stitch Machine.
JUKI’s cutting-edge dry-head technology has been introduced to the MO-6700S, which has an established reputation for its excellent seam quality and higher productivity. Only the parts which mainly contribute to oil splashes are improved to have dry mechanisms to create the semi-dry-head overlock machine, MO6700DA series. The MO-6700DA Series is the best selling machine to eliminate oil stains on the sewing product.
Pricing and Availability on Request
Why Buy from Us?
- You are dealing with the official Juki Sewing Machine UK Importing and Distributing Network
- Your machine enquiry will be passed onto your local Juki dealer who will quote, setup, and install your new machines. As well as providing full after sales support and warranty
- Our centralised distribution warehouse supplies Juki machinery to all Juki Traders, providing the best possible service and local contact for your sewing requirements
Description / JUKI MO-6716DA-DE6-307 3.2 x 4MM 5 THREAD OVERLOCK DRY HEAD
Juki MO-6716DA-DE6-307
- Semi-dry-head, 2-Needle 5-Thread, High-speed, Light- to Medium-Weight Overlock / Safety Stitch Machine.
JUKI’s cutting-edge dry-head technology has been introduced to the MO-6700S, which has an established reputation for its excellent seam quality and higher productivity.
Only the parts which mainly contribute to oil splashes are improved to have dry mechanisms to create the semi-dry-head overlock machine, MO6700DA series. The MO-6700DA Series is the best selling machine to eliminate oil stains on the sewing product.
Oil stains on the sewing product are eliminated
- Oil splashes are substantially reduced to eliminate oil stains on sewing products, thereby upgrading the finished quality.
- The frequency of stain removal or re-sewing is reduced.
- The machine achieves a practical maximum sewing speed of 7,000sti/min.
Cutting-edge dry technology for achieving a lubrication-free mechanism
- The needle bar mechanism and upper looper mechanism have been re-designed to require no lubrication.
- The most-advanced dry technologies, such as the special surface treatment applied to the major drive unit and the grease feeding method, contribute to higher durability. The machine does not splash oil after a long-period of use. The grease filler openings are newly provided for the sewing machine on two locations, i.e., one on the upper looper component and the other on the sewing machine frame, thereby improving maintainability.
Subclass Specification
| Subclass Model | Juki MO-6716DA-DE6-307 |
|---|---|
| Material | Light- to Medium-Weight |
| Number of Needles | 2 |
| Number of Threads | 5 |
| Needle Gauge | 3.2 |
| Overedging Width | 4.0mm |
| Number of Feed Dog Rows | 3 |
| Stitch Length | 4mm |
| Bottom differential-feed ratio | 1:07~1.2 |
| Presser lifting amount | 7mm |
| Needle system | DCx27 #11 |
| Max sewing speed | 7,000 sti/min |
| Remarks | Upper looper high-throw type |
* “sti/min” stands for “Stitches per Minute”
Technical Specification
| Model name | Juki MO-6716DA |
|---|---|
| Stitch type | Safety stitching |
| Stitch style in the U.S.A. | 516 |
| Max. sewing speed | 7,000sti/min* |
| Stitch length | 1.5~4mm |
| Needle gauge (mm) | 3.2, 4.8, 4.8+2.0, 3.2+2.0 |
| Overedging width (mm) | 3.2, 4.0, 4.8, 6.4 |
| Bottom differential feed ratio | For gathering 1:2 (Max. 1:4), For stretching 1:0.7 (Max. 1:0.6) |
| Needle bar stroke | 24.5mm |
| Inclination angle of the needle | 20° |
| Needle mechanism | Needle bar method and upper /lower bushing |
| Needle | DC×27 (excluding some subclass model) |
| Max. lift of the presser foot | 7mm (excluding some subclass model) |
| Max. presser foot pressure | 63.7N (6.5kgf) |
| Stitch adjusting method | By push-button |
| Differential-feed adjusting method | By lever (with micro-adjustment) |
| Weight of the machine head | 28kg |
| Lubrication | Automatic (The needle bar mechanism and upper looper mechanism do not requ ire lubrication.) |
| Lubricating oil | JUKI Machine Oil 18 (equivalent to ISO VG18) |
| Needle cooler | Option |
| Needle thread heat remover | Option |
| Micro-lifter | Provided as standard |
* “sti/min” stands for “Stitches per Minute”
More Information
| Part No | JUKIMO6716DADE6307 |
|---|---|
| Weight (KG) | 32.000000 |
| Manufacturer | Juki |
