Description / JUKI PLC-2760RDV8-HMC 2N POST M/CH DECORATIVE STITCH
JUKI PLC-2760RDV8-HMC
2-needle, Semi-dry, Post-bed, Unison-feed, Lockstitch Machine with Vertical-axis 2.0 Fold-Capacity Hook, Decorative Stitch
A turning needle bar system with dedicated control box allows for abundant variety of different stitching patterns. The stitch length can be adjusted electronically making for much simpler interface for the operator. New stitch patterns can be added easily to the interface.
This is a 2-needle, Semi-dry, Post-bed, Unison-feed, Lockstitch Machine with a turning needle bar system with dedicated control box to allow for abundant variety of stitching patterns to be created that are normally not possible on a regular post-bed sewing machine. The stitch length can be adjusted electronically making for much simpler interface for the operator and also allowing for new stitch patterns tp be added easily. This machine is available exclusivly from Juki Central Europe and it had been made in cooperation with Riveco Automazione.
A dedicated control box and software with easy to navigate interface guarantees hassle-free selection from variety of different stitching patterns and adjusting of a stitch length. A turning needle bar system allows for abundant stitching pattern applications.
Technical Specification
| Model name | Juki PLC 2760RDV8-HMC |
|---|---|
| Type | 2-needle organized split needlebars type (V-belt type) |
| Max. Sewing speed | 2,500sti/min* |
| Needle | 135×17 Nm100~180 Standard Nm140 |
| Thread | TEX 50~167 |
| Max. stitch length | 12mm (forward / backward) |
| Stitch adjusting method | 1 pitch dial |
| Thread take-up | Link type |
| Automatic reverse feed function | Lever type |
| Needle bar stroke | 40mm |
| Hook | Vertical-axis 2.0-fold capacity hook (latch type) |
| Lift of the presser foot | By hand: 10mm Auto: 18mm |
| Alternating vertical movement | 1~9mm |
| Alternating vertical movement adjusting method | Dial |
| DL device | Provided as standard |
| Safety mechanism | Provided as standard |
| Bobbin thread winder | Built in the machine arm |
| Bottom-feed micro-adjustment mechanism | Provided as standard |
| Lubrication | Automatic (Tank system) |
| Distance from needle to machine arm | 347mm |
| Post height | 170mm |
| Knee-lifter | Provided as standard |
| Auto-lifter | Option |
| Weight of the machine head | 80kg |
| Power requirement / Power consumption | Single-phase 100~120V / 200~240V 3-phase 200~240V / 193VA (with automatic thread trimmer) |
| Air consumption | 0.1dm³/min (ANR) |
*1 The maximum sewing speed is limited by the amount of the alternating vertical movement of the walking foot and presser foot and stitch length.
More Information
| Part No | JUKIPLC2760RDV8 |
|---|---|
| Weight (KG) | 32.000000 |
| Manufacturer | Juki |
